Athermalized IR Lens 13mm F/1.0 (For Industrial Machine Vision) Description
Athermalized IR (Infrared) Lens (For Industrial Machine Vision) is a specially designed infrared optical lens that compensates for temperature changes, maintaining focus without needing manual adjustment across a wide range of temperatures. These lenses are used in systems where temperature stability is crucial, such as thermal imaging cameras, infrared sensors, and other devices operating in variable environmental conditions.
Athermalized IR Lens 13mm F/1.0 (For Industrial Machine Vision) Application
Athermalized IR Lens 13mm F/1.0 (For Industrial Machine Vision) is widely used in laser, medicine, astronomy, infrared night vision and other fields.
Athermalized IR Lens 13mm F/1.0 (For Industrial Machine Vision) Packing
Our Athermalized IR Lens 13mm F/1.0 (For Industrial Machine Vision) is carefully handled during storage and transportation to preserve the quality of our product in its original condition.
|
HFOV
|
160x120
|
384x288
|
640x512
|
1024x768
|
|
25μm
|
17.49
|
-
|
-
|
-
|
|
17μm
|
11.94
|
28.19
|
-
|
-
|
|
12μm
|
8.45
|
20.1
|
32.91
|
-
|
Optical Properties
|
Focal Length (mm)
|
13mm
|
|
F/#
|
1.0
|
|
Average Transmission
|
>83%
|
|
Back Focal Length
|
9.12mm
|
Environmental Durability
|
Operating Temperature
|
-40℃ to +80℃
|
|
Storage Temperature
|
-50℃ to +80℃
|
|
Protection Rating
|
IR68
|
|
First Surface Coating
|
DLC
|
Mechanical Properties
|
Focusing Range
|
0.3m~∞
|
|
Back Working Distance
|
9mm
|
|
Detector Interface Size
|
M20 x 0.5-6g
|
|
Overall Dimensions (mm)
|
Φ24 x 18.5
|
|
Weight
|
20g
|
*For drawing, please contact us.
