MPO-LC Duplex Breakout Cable Description
MPO-LC Duplex Breakout Cable, 12F, G657A2, LSZH-1, Type B, 3m is a high-performance single-mode fiber optic assembly designed for dense network environments requiring fast, low-loss connectivity. Built with G657A2 bend-insensitive fiber, it ensures superior signal integrity even in tight routing spaces. This cable features one MPO female connector and six duplex LC connectors, providing efficient breakout from trunk cables to active equipment. The Type B polarity enables correct channel mapping, while the LSZH-1 (Low Smoke Zero Halogen) outer jacket enhances safety by minimizing toxic emissions in case of fire. Each cable is factory-terminated and 100% tested to ensure consistent quality and performance in data centers, telecom systems, and enterprise infrastructure.
MPO-LC Duplex Breakout Cable Applications
Data Centers
- High-density breakout from MPO backbone trunks to LC-based switches or transceivers
- Ideal for single-mode 40G/100G connectivity
- Space-saving deployment with bend-insensitive G657A2 fiber
Enterprise Networks
- Structured cabling between telecom rooms and distribution equipment
- Supports low-loss, high-performance single-mode transmission over long distances
- Suitable for cable routing in tight office or server room spaces
Telecommunications
- Backbone interconnects between ODFs, cross-connects, and equipment racks
- Reliable single-mode optical connections for central offices and exchanges
Public Sector, Education & Healthcare
- Fire-safe fiber cabling with LSZH jacket for compliance with building safety codes
- Long-distance fiber runs supporting mission-critical communication infrastructure
MPO-LC Duplex Breakout Cable Packaging
Our products are packaged in customized cartons of various sizes based on the material dimensions. Small items are securely packed in PP boxes, while larger items are placed in custom wooden crates. We ensure strict adherence to packaging customization and the use of appropriate cushioning materials to provide optimal protection during transportation.
Packaging: Carton, Wooden box, Paper barrel, Iron barrel, or Customized.
Product Features
- Complies with TIA/EIA-568-C.3 and ISO/IEC 11801 standards
- 100% factory-terminated and tested before shipment
- Flexible cable polarity options available
- Each cable is labeled for production tracking and quality traceability
|
Fiber Count
|
12 Fibers
|
|
Sheath Material
|
LSZH-1
|
|
Polarity Configuration
|
Type B
|
|
Standards
|
IEC 61754-7
IEC 61754-20
IEC 61300-3-4
TIA/EIA-568-C.3
ISO/IEC 11801
|
|
Fiber Performance
|
|
Fiber Type
|
G.657.A2
|
|
Core/Cladding Diameter (μm)
|
9/125
|
|
Effective Modal Bandwidth (MHz·km)
|
N/A
|
|
Operating Wavelength (nm)
|
1310 / 1550
|
|
Maximum Attenuation (dB/km)
|
0.35 / 0.21
|
|
Connector Performance
|
|
Loss Grade
|
MPO Multimode High Precision
|
|
IL (Insertion Loss, dB)
|
≤ 0.25
|
|
High-Low Temperature Cycle ΔIL (dB)
|
≤ 0.20
|
|
RL (Return Loss, dB)
|
≥ 25
|
|
High-Low Temperature Cycle ΔRL (dB)
|
≤ 5
|
|
Mechanical Properties
|
|
Number of Optical Fibers
|
12 fibers
|
|
Min. Static Bending Radius
|
10D mm
|
|
Min. Dynamic Bending Radius
|
20D mm
|
|
Operating Temperature
|
-20~+60 °C
|
|
Installation Temperature
|
-5~+50 °C
|
|
Storage and Transport Temperature
|
-25~+75 °C
|
*The above product information is based on theoretical data. For specific requirements and detailed inquiries, please contact us.
